Jumbo B
Code | 0201011.50 Ø9 |
---|---|
Diameter | 415 mm |
Height | 630 mm |
Gutter depth | 45 mm |
Gutter width | 50 mm |
Weight | 1,86 kg |
Capacity | 60/70 adult broilers/breeders |
Standard packing | 20 pcs per carton 640x420x730 mm |
Shipping capacity | 2700 pcs = 20' cnt |
Jumbo-B bell drinker is a drinker for breeders and it can be used either on the floor or hanged.
It is supplied with a specific ballasted bell to be placed under the red bell and filled with water or, for more stability, with sand (used as ballast), in order to avoid drinker’s shaking and consequent water leaking in the poultry house.
This Jumbo-B bell drinker can be used from first day till slaughtering age and can host till 100 heads per unit, according to slaughtering weight and climate conditions.
The fully ABS-plastic made valve reduces internal wear of threads, providing total security, big reliability and high performances of the drinkers, minimizing the possibilities of water flooding.
OPERATING SPECIFICATIONS
Working pressure: min 0.2 bar – max 0.5 bar.
For higher pressures, either use a reducer or connect to a water tank that should be placed at least 4 m above ground level.
For optimum working conditions, it is suitable to keep the water level beetween 10 to 20 mm.
Image | Code | Description |
---|---|---|
0480001.50 | Shut-off Saddle Ø9 | |
0505107.50 | Hose hook Ø9 | |
0505106.50 | Cord adjuster | |
0604001.50 | Rubber hose 5x9 | |
0505111.50 | Suspension cord | |
0505119.50 | Suspension hook | |
0201111.50 | Locknut | |
0501111.50 | Hose connector Ø9 | |
0201107.50 | Water level control | |
0506002.50 | Valve | |
0201108.50 | Collar | |
0201102.50 | Bell | |
0505114.50 | Spring | |
0201106.50 | Stem | |
0201112.50 | Plug | |
0201104.50 | Cover | |
0201105.50 | Base | |
0201103.50 | Ballast complete | |
0504001.50 | Complete valve Ø9 | |
0480002.50 | Shut-off saddle Ø14 | |
0604002.50 | Rubber hose 10x14 | |
0504002.50 | Valve complete Ø14 |
Image | Code | Description |
---|---|---|
0201109.50 | Chick ring | |
0503002.50 | Threaded T Ø9 | |
0503003.50 | Threaded T Ø14 |
